SHM Physics M.5: Problems And Solutions

by TextBrain Team 40 views

Hey guys! Physics can be a tough subject, especially when you dive into Simple Harmonic Motion (SHM). But don't worry, I'm here to help you tackle those tricky problems. This article is packed with SHM physics problems tailored for Mathayom 5 (Grade 11) students, complete with detailed solutions. Let's get started and make SHM a breeze!

What is Simple Harmonic Motion (SHM)?

Before we dive into the problems, let's quickly recap what Simple Harmonic Motion (SHM) actually is. SHM is a special type of periodic motion where the restoring force is directly proportional to the displacement, and acts in the opposite direction. Think of a spring being stretched or compressed – the farther you pull it, the harder it pulls back. This results in a smooth, oscillating motion around an equilibrium point.

Key characteristics of SHM include:

  • Periodic Motion: The motion repeats itself after a fixed interval of time (the period).
  • Equilibrium Point: The point where the object is at rest, and the net force on it is zero.
  • Restoring Force: A force that always pulls the object back towards the equilibrium point. This force is proportional to the displacement from the equilibrium point.
  • Amplitude: The maximum displacement from the equilibrium point.
  • Period (T): The time taken for one complete oscillation.
  • Frequency (f): The number of oscillations per unit time (usually seconds). It's the inverse of the period (f = 1/T).
  • Angular Frequency (ω): Related to the frequency by the equation ω = 2πf.

Understanding these concepts is crucial for solving SHM problems. Make sure you're comfortable with them before moving on.

Example Problems and Solutions

Alright, let's get our hands dirty with some example problems! I'll walk you through each problem step-by-step, explaining the logic and formulas involved. Get ready to sharpen those physics skills!

Problem 1: The Spring-Mass System

Problem: A 2 kg mass is attached to a spring with a spring constant of 200 N/m. The mass is displaced 0.1 m from its equilibrium position and released. Determine:

  • The angular frequency of the oscillation.
  • The period of the oscillation.
  • The maximum velocity of the mass.

Solution:

First, let's identify the given values:

  • Mass (m) = 2 kg
  • Spring constant (k) = 200 N/m
  • Amplitude (A) = 0.1 m
  1. Angular Frequency (ω):

The angular frequency of a spring-mass system is given by:

ω = √(k/m)

Plugging in the values, we get:

ω = √(200 N/m / 2 kg) = √100 s⁻² = 10 rad/s

  1. Period (T):

The period is related to the angular frequency by:

T = 2π/ω

So, T = 2π / 10 rad/s ≈ 0.628 s

  1. Maximum Velocity (v_max):

The maximum velocity occurs when the mass passes through the equilibrium position and is given by:

v_max = Aω

Therefore, v_max = 0.1 m * 10 rad/s = 1 m/s

Answer:

  • Angular frequency: 10 rad/s
  • Period: 0.628 s
  • Maximum velocity: 1 m/s

Problem 2: The Simple Pendulum

Problem: A simple pendulum has a length of 1 meter. What is the period of its oscillation, assuming small angles?

Solution:

Given:

  • Length (L) = 1 m
  • Acceleration due to gravity (g) = 9.8 m/s² (approximately)

For a simple pendulum, the period is given by:

T = 2π√(L/g)

Plugging in the values:

T = 2π√(1 m / 9.8 m/s²) ≈ 2π√(0.102 s²) ≈ 2π * 0.319 s ≈ 2.00 s

Answer: The period of the pendulum is approximately 2.00 seconds.

Problem 3: Energy in SHM

Problem: A 0.5 kg mass is oscillating in SHM with an amplitude of 0.2 m and a frequency of 2 Hz. Calculate the total energy of the system.

Solution:

Given:

  • Mass (m) = 0.5 kg
  • Amplitude (A) = 0.2 m
  • Frequency (f) = 2 Hz

First, we need to find the angular frequency:

ω = 2πf = 2π * 2 Hz = 4π rad/s

The total energy (E) in SHM is given by:

E = (1/2) * m * ω² * A²

Plugging in the values:

E = (1/2) * 0.5 kg * (4π rad/s)² * (0.2 m)²

E = (1/2) * 0.5 kg * 16π² (rad/s)² * 0.04 m²

E ≈ 0.5 * 0.5 * 16 * 9.87 * 0.04 J

E ≈ 0.158 J

Answer: The total energy of the system is approximately 0.158 Joules.

Tips for Solving SHM Problems

  • Understand the Concepts: Make sure you have a solid grasp of the definitions and formulas related to SHM.
  • Identify Given Values: Carefully read the problem and list all the known values with their units.
  • Choose the Right Formula: Select the appropriate formula based on the information given and what you need to find.
  • Check Your Units: Ensure that all units are consistent before plugging them into the formula.
  • Draw Diagrams: Visualizing the problem with a diagram can often help you understand the motion and identify relevant variables.
  • Practice, Practice, Practice: The more problems you solve, the better you'll become at recognizing patterns and applying the correct techniques.

Common Mistakes to Avoid

  • Confusing Period and Frequency: Remember that period (T) is the time for one oscillation, while frequency (f) is the number of oscillations per second. They are inversely related (T = 1/f).
  • Using the Wrong Formula: Make sure you're using the correct formula for the specific situation (e.g., spring-mass system vs. simple pendulum).
  • Ignoring Units: Always pay attention to units and make sure they are consistent throughout the calculation.
  • Forgetting the Small Angle Approximation: For simple pendulums, the formula T = 2π√(L/g) is only valid for small angles (typically less than 15 degrees).

Practice Problems

Want to put your skills to the test? Here are a few more practice problems for you to try:

  1. A spring with a spring constant of 150 N/m is stretched by 0.08 m when a mass is attached. What is the mass?
  2. A pendulum with a length of 0.5 m is released from an angle of 10 degrees. What is its maximum velocity?
  3. A 1 kg mass is oscillating in SHM with a period of 1.5 s and an amplitude of 0.15 m. What is its maximum kinetic energy?

Conclusion

So there you have it! A comprehensive guide to solving SHM physics problems. Remember, the key to success is understanding the fundamental concepts, practicing regularly, and avoiding common mistakes. Good luck with your studies, and keep oscillating! Don't be afraid to ask for help when you need it. Physics can be fun if you approach it with the right mindset. Keep practicing, and you'll master SHM in no time! You got this, guys!
